| PARAMETERS |
DG MODELS |
| 50 HZ PRIME |
Rating(kVA) |
75 kVA |
82.5 kVA |
100 kVA |
125 kVA |
| Rated(kWe) |
60 |
60 |
66 |
80 |
100 |
| Engine Model |
41035GM-C2 |
41035GM-C2 Standby |
82.5 kVA Mech CPCB II |
100 kVA Mech CPCB II |
125 kVA Mech CPCB II |
| No of Cylinders |
4 |
4 |
4 |
4 |
6 |
| Rated Speed RPM |
1500 |
| Rated Engine Power at 100% load KW (HP) |
68.9 (93.6) |
|
74.5 (101.2) |
93 (126.4) |
114.8 (156) |
| Rated Current(AMP) Capacity @ 0.8PF |
1 Phase |
NA |
| 3 Phase |
104.3 |
|
115 |
139 |
173.9 |
| Door Type |
DD |
DD |
DD |
DD |
| Side lifting DG set dimensions with top hood, if any (mm) |
Length |
3000 |
|
3200 |
3200 |
- |
| Width |
1150 |
|
1300 |
1300 |
- |
| Height |
2135 |
|
2290 |
2290 |
- |
| Intergrated Fuel Tank Capacity (lits) |
230 |
|
200 |
200 |
219 |
| Approximate Weight of DG set (Kg) |
1350 |
|
1700 |
1720 |
1866 |
| Centre lifting DG set dimensions with top hood, if any (mm) |
Length |
2800 |
|
3200 |
3200 |
3750 |
| Width |
1150 |
|
1300 |
1300 |
1030 |
| Height |
1640 |
|
1700 |
1700 |
1533 |
SL = Side Lifting
CL = Center Lifting
SD = Single Door
DD = Double Door
