| PARAMETERS |
DG MODELS |
| 50 HZ PRIME |
Rating(kVA) |
50 kVA |
62.5 kVA |
| Rated(kWe) |
40 |
50 |
| Engine Model |
4725GM-C2 |
4905GM-C2 |
| No of Cylinders |
4 |
4 |
| Rated Speed RPM |
1500 |
1500 |
| Rated Current(AMP) Capacity @ 0.8PF |
1 Phase |
NA |
| 3 Phase |
69.6 |
87 |
| Cooling System (Air Cooled/Water Cooled) |
Water |
Water |
| Door Type |
DD |
DD |
| Side lifting DG set dimensions with top hood, if any (mm) |
Length |
2770 |
2770 |
| Width |
1150 |
1150 |
| Height |
1800 |
1800 |
| Intergrated Fuel Tank Capacity (lits) |
150 |
150 |
| Approximate Dry Weight of DG set (Kg) |
1250 |
1250 |
| Centre lifting DG set dimensions with top hood, if any (mm) |
Length |
2800 |
2800 |
| Width |
1150 |
1150 |
| Height |
1540 |
1540 |
SL = Side Lifting
CL = Center Lifting
SD = Single Door
DD = Double Door
